PLACA MÃE GALAX H510MH INTEL LGA 1200 DDR4 MICRO ATX

Marca: Galax
Part number: IH510MAGCGY1CW

Processadores Intel de 11th Geração, Core I9. Core I7, Core I5, Pentium® Gold e Celeron
Processadores Intel de 10th Geração, Core I9. Core I7, Core I5, Pentium® Gold e Celeron
Socket: 1200
CPU chipset: IIntel H510
CPU:Intel® 10th e 11Th geração:

Memória:
02 x DIMM, Max. 64GB, DDR4 2133/2400/2666/2933 ( Dual channel,)
Suporta até 32GB de memória.

Armazenamento:
04- Portas sata SATA 6Gb/s
01- M.2 PCIe 32Gbps compativel com sata II

Expansion slot :
01 - PCI-E 3.0x16
01- PCI-E 3.0x1

Saídas de video:
01 - VGA
01- HDMI

Portas USB:
04 USB 3.1 (2 no painel traseiro, 2 para o gabinete )
06 USB 2.0 (4 no painel traseisro, 2 para o gabinete)

Audio e rede
Audio: 6-channel HD Audio CODEC, ALC662_VD
Rede Lan: Intel®, 1 x Gigabit LAN Controller(s) RTL8111H

Conectores externos:
1 x VGA
1 x DVI
1 x HDMI
1 x LAN (RJ45) port(s)
2 x USB 3.2 gen1
4 x USB 2.0
1 x PS/2
3 x Audio jack(s)

Conectores internos:
1 x USB 3.2 Gen1 connector(s) support(s) additional 2 USB 3.2 Gen1 port(s)
1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)
4 x SATA 6Gb/s connector(s)
1×M.2 PCIe 32Gbps compatible with SATA III
1 x CPU Fan connector(s) (4 -pin)
2 x Chassis Fan connector(s) (4 -pin)
1 x Debug connector(s) (4 -pin)
1 x 24-pin Power connector(s)
1 x 8-pin 12V Power connector(s)
1 x Front panel audio connector(s)
1 x Front panel connector(s)
1 x Clear CMOS connector(s)
1 ×Com connector(s)
1 x Speak connector(s)

Peso bruto: 0,6Kg
Dimensão: 5,5cm x 26cm x 27,2cm (Altura x Largura x Comprimento)
